If you are building RAG, agent memory, or internal search over sensitive data, the usual vector DB setup can feel like a bad tradeoff. You get semantic search, but the storage layer can still read your documents, vectors, and queries.

XTrace is built for a different model. This post gives you the fast version of how to set it up, and the full video walkthrough is below.

How to Set Up a Private Vector DB with XTrace

If you want the full walkthrough, watch the setup video. If you want the fast version, this post will get you oriented in a few minutes.

XTrace lets you run vector search without giving the server readable access to your documents, vectors, or queries. The detailed setup is already covered in the video, so this post is here to make the flow easy to scan and easy to remember.

Watch the full video walkthrough: https://youtu.be/gt7RwVD9eEc

What you are doing

At a high level, the setup looks like this:

1. Get your API key

2. Install the CLI

3. Initialize your session

4. Create your execution context

5. Create a knowledge base

6. Write files into it

7. Run semantic search

That is the whole flow.

1. Get your API key

Start by creating an account in the XTrace app and generating your API key.

If you are using the admin flow shown in the video, you will also want your:

• organization ID

• admin key

Store them somewhere secure.

2. Install the CLI

The video uses the XTrace CLI to get started because it is the fastest way to explore the private vector DB flow.

Once the package is installed and the xtrace command is available in your terminal, you are ready to move on.

If you want exact commands, use the video and docs side by side.

3. Initialize your session

Open the XTrace shell and run the init flow.

This is where you enter your credentials and choose how your local setup will work. If you are following the demo, this is done in admin mode.

This part matters because XTrace is not just asking for a hosted API connection. It is setting up the local context that will control how your encrypted data is accessed.

4. Create your execution context

This is the most important concept in the setup.

Your execution context is the local object on your machine that holds the credentials and encryption material needed to access your data.

It includes the keys that protect:

• your vectors

• your content

Those keys are locked behind a passphrase.

That passphrase matters a lot. If you lose it, you lose the ability to decrypt your data. So do not treat it like a throwaway setup step. Treat it like the key to the system.

5. Choose your embedding model

In the video, the privacy-friendly path is to use a local embedding model.

That keeps more of the pipeline on your own machine and fits the whole point of a private vector database. You are not trying to build a setup where the storage layer is blind, then immediately send raw content somewhere else upstream without thinking about it.

6. Create a knowledge base

Once your execution context is ready, create a knowledge base.

A knowledge base is the container for the encrypted documents and vectors you want to work with.

The clean way to think about it is:

• execution context = how your machine unlocks and accesses data

• knowledge base = where your encrypted data lives

7. Write files into the knowledge base

Now you can load files.

This is where the difference between XTrace and a normal vector DB becomes concrete. You are not just uploading plaintext documents into a searchable system. The documents are encrypted before upload, and the vectors are encrypted too.

The server stores ciphertext, not readable source material.

8. Run semantic search

Once your knowledge base has data in it, you can search it.

In the XTrace model, the query is encrypted before it is sent. The server performs search on encrypted data, then returns encrypted results, which are decrypted locally.

That is the whole point of the setup.

You still get semantic search. But the infrastructure does not get readable access to the underlying data.

Things to pay attention to

Your passphrase

This is the big one.

If you forget it, you lose the ability to decrypt your data. Pick something strong and store it safely.

Your embedding model choice

If privacy is the goal, think through your embedding setup too. A local model is the cleanest fit for this flow.

Your metadata

Even in systems built for privacy, metadata design still matters. Do not casually put sensitive identifiers into metadata fields unless you are sure that is how you want the system to behave.

Who this is for

This setup makes the most sense if you are building:

• RAG over sensitive documents

• internal enterprise search

• legal or healthcare retrieval systems

• AI memory systems

• agents that should remember without exposing that memory to the storage layer

If that is your use case, this flow is worth understanding.

Where to go next

For the full walkthrough, watch the video:

YouTube walkthrough: https://youtu.be/gt7RwVD9eEc

For the latest implementation details and docs:

Docs: https://docs.xtrace.ai

And if you have not read the earlier posts in this series yet:

• Your Vector Database Can Read Your Data

• “Encrypted at Rest” Doesn’t Mean Private

The short version is simple:

Your vector DB should not be able to read your data.
